                     Multi Size Testing Plugs









      (Click picture for larger view)


 Multi Size Testing Plugs

Product Code Size Range mm Inflation PSI/Bar Back pressure PSI/Bar By pass Length Width Weight
123-650-0406 100-150 35/2.4 10/.7 8X12 330 90 1
123-650-0610 150-250 35/2.4 14.5/1 8X12 560 127 3.5
123-650-0612 150-300 35/2.4 14.5/1 8X12 600 125 6.5
114-BP200 200-400 29/2.0 19/1.3-10/.07 50 500 180 8
123-650-0812 200-300 35/2.4 14.5/1 8X12 575 178 4.5
123-650-1016 225-400 35/2.4 14.5/1 8X12 635 224 7.3
114-BP300 300-600 29/2.0 19/1.3-10/.07 50 290 700 17
123-650-1218 275-450 35/2.4 14.5/1 8x19 610 267 10
123-650-1224 275-625 25/1.7 13/.9 8x19 1195 267 14
123-650-1521 350-550 35/2.4 14.5/1-10/.7 8x19 800 330 13
123-650-1824 400-625 35/2.4 14.5/1-10/.7 8x19 900 394 17.5
123-650-1830 425-775 25/1.7 14.5/1-10/.7 8x19 1195 405 31
123-650-2036 475-950 25/1.7 14.5/1-10/.7 8x19 1650 457 43
114-BP500-1000 500-1000 29/2.0 19/1.3-9/.06 50 1350 440 52
114-BP500-1200 500-1200 29/2.0 19/1.3-7/.05 100 1650 440 60
123-650-2448 575-1250 25/1.7 14.5/1-10/.7 8x19 2285 545 66
123-650-3660 900-1550 20/1.4 14.5/1-8/.6 8x19 2286 865 107
123-650-4278 1050-2000 14.5/1 6/.4 8x19 2590 1015 136
123-650-4872 1200-1850 20/1.4 14.5/1-8/.6 8x19 2290 1170 147
123-650-6096 1500-2450 12/.8 6/.4 8x19 2800 1475 250
